Basic structure and composition
CBN abrasive layer:
High-purity cubic boron nitride (CBN) particles are fixed on the surface of the metal substrate through an electroplating process.
Substrate material:
High-strength 45# steel or aluminum alloy is used.
Binder:
Electroplated nickel is used as a binder.
Advantages:
High hardness and strong thermal stability, suitable for processing hardened steel, high-speed steel and other ferrous metals.
| Size | Diameter | TS | Inner hole | W/M | Grit |
| 12" | 300mm | 15.875mm(5/8") |
17.25mm |
10/30 |
B126 B151 B251 |
Of course, We can customize the size according to your requirements
Available Wheel Profiles:
* 10/30 - Mostly Used Universal Grinding Wheel Profile
* 9/29 - Perfectly Prepares Band Saws For Winter Time Cutting, Or Cutting Hard Wood
* 13/29 - Wheel Profile Which Prepares Band Saws For Soft Wood Cutting
* 4/32 - Wheel Profile Which Can Prepare Band Saws For Very Frozen And Very Hard Wood Cutting
* 7/34 The CBN Wheels Profile Is Recommended For Hardwood
